The three-dimensional flexible welding platform for triple frequency five axis laser cutting is a welding equipment specially designed to match the triple frequency five axis laser cutting process. It has the following characteristics and advantages:

High accuracy: the surface of the platform and the positioning hole have extremely high machining accuracy and high flatness. The position accuracy and dimensional accuracy of the positioning hole can meet the high accuracy requirements of welding after laser cutting. The general flatness tolerance can be controlled within ± 0.05mm/m, and the center tolerance of the positioning hole is within ± 0.05mm, ensuring the dimensional accuracy and geometric tolerance of the welding workpiece, making the welding quality more stable and reliable.

High flexibility: it adopts modular design and is composed of a variety of standard modules. According to different laser cutting workpiece shapes, sizes and welding process requirements, it can be quickly combined into tooling fixtures of various shapes and sizes, which can adapt to the welding production of a variety of products, and can quickly switch different welding tooling configurations to meet the production requirements of multiple varieties and small batches.

Good compatibility: it works well with the triple frequency five axis laser cutting equipment, and can match the working area and motion trajectory of the laser cutting machine, which is convenient for direct welding operation after cutting, reducing the handling and relocation of workpieces, and improving production efficiency and processing accuracy. At the same time, it can also be used with various welding equipment and robots to realize automatic welding production.

Strong bearing capacity: it can bear the weight of the workpiece after laser cutting and various forces during welding. Generally, platforms with different bearing capacity can be selected according to actual needs, ranging from a few tons to dozens of tons, to ensure that the platform will not be deformed during welding and ensure welding accuracy.

Good corrosion resistance and wear resistance: it is usually made of high-quality cast iron or steel parts and subject to special surface treatment, such as heat treatment, rust prevention treatment, etc., which has good corrosion resistance and wear resistance, and can resist the erosion and wear of high temperature and spatter generated in the process of laser cutting and welding, so as to extend the service life of the platform.

Convenient operation: the module design of the platform is convenient for installation, disassembly and adjustment, and the operator can quickly assemble and replace the fixture as required, reducing the production preparation time. At the same time, the scale and module size on the platform are designed reasonably, and the operator can quickly build the required tooling according to the workpiece size without measuring tools, so as to improve the work efficiency.

In practical applications, this three-dimensional flexible welding platform is widely used in automotive manufacturing, aerospace, electronic equipment manufacturing and other industries. For example, in automobile manufacturing, it is used for the welding of automobile body parts; In the field of aerospace, it is used for the welding of aircraft structural parts; In the manufacture of electronic equipment, it is used for the welding of precision metal structures. It can improve welding quality and production efficiency, reduce production costs, and is one of the indispensable welding equipment in modern manufacturing industry.
