Cast Iron Cnc Machine

Cast Iron Cnc Machine Structural characteristics

Cast iron body:The body is made of cast iron material,which has high rigidity,high strength,and good shock absorption performance.The organizational structure of cast iron is stable and can withstand the impact force and vibration generated by high-speed cutting and heavy load machining of machine tools,ensuring the accuracy maintenance of machine tools.

High precision moving parts:equipped with high-precision ball screws,linear guides and other moving parts.Ball screws can achieve precise feed motion,ensuring the accuracy of machining dimensions;Linear guides have high rigidity and low friction coefficient,allowing moving parts such as workbenches to move smoothly and quickly,improving machining efficiency and surface quality.

Spindle system:High performance spindles are usually used,which have the characteristics of high speed,high precision,and high torque.The accuracy and stability of the spindle directly affect the machining accuracy and surface roughness.Some advanced cast iron CNC machine tools are equipped with automatic tool changing devices on the spindle,which can achieve fast tool changing and improve machining efficiency.

Numerical Control System:Equipped with advanced numerical control systems,such as control systems from brands like Siemens and Fanuc.The numerical control system has powerful programming functions and control accuracy,which can realize the machining of complex parts.By accurately controlling the motion of each coordinate axis of the machine tool,high-precision machining trajectories can be achieved.

Processing advantages

High precision machining:Due to the high rigidity structure and high-precision moving parts of the machine tool,cast iron CNC machine tools can achieve high-precision machining.It can process parts with dimensional accuracy at the micrometer level,meeting the strict requirements for part accuracy in industries such as aerospace,automotive manufacturing,and mold manufacturing.

High surface quality:During the machining process,the stability and precise motion control of the machine tool can ensure the relative motion accuracy between the tool and the workpiece,thereby achieving good surface quality.The surface roughness of the processed parts is low,which can reduce subsequent polishing,grinding and other processes,and improve production efficiency.

Complex shape processing:With the powerful programming function of CNC systems,cast iron CNC machine tools can process various complex shaped parts,such as impellers,blades,mold cavities,etc.By writing complex machining programs and controlling the multi axis linkage of machine tools,three-dimensional surface machining of parts can be achieved.

Automated processing:characterized by a high degree of automation,it can achieve mass production of parts.Once the machining program is written,the machine tool can automatically process according to the program,reducing manual intervention and improving production efficiency and consistency in machining quality.
