Granite Straight Edge 00 precision grade .OEM with design

A granite straight edge of 00 precision grade is a high-quality metrology tool.Here's what you need to know about it,especially in the context of OEM with design:

Characteristics of 00 Precision Grade Granite Straight Edge

Exceptional Straightness:The 00 precision grade implies that the straight edge has an extremely high level of straightness.It can have a straightness tolerance of within a few micrometers over its length.For example,a 300-mm-long granite straight edge of 00 grade may have a straightness error of less than 2μm,providing a very accurate straight reference for measurement and inspection.

High-Quality Granite Material:It is made from high-quality granite,which offers excellent stability.Granite has a low coefficient of thermal expansion,so it is not easily affected by temperature changes.This ensures that the straight edge maintains its dimensional stability and straightness accuracy under different environmental conditions.Additionally,granite is highly wear-resistant and has good corrosion resistance,which helps to maintain its surface quality and performance over a long period.

Applications

Precision Machining:In the manufacturing of precision parts,the granite straight edge is used to check the straightness of machined surfaces.It can be used to verify if the edges of components such as shafts,guide rails,and machine tool beds are straight within the required tolerance.By placing the straight edge against the surface to be measured and using measuring instruments like dial indicators or optical comparators,any deviations from straightness can be accurately detected.

Metrology and Calibration:In metrology laboratories,it serves as a standard for calibrating other measuring instruments related to straightness measurement,such as straightness measurement probes and laser interferometers.The 00-grade granite straight edge provides a reliable reference for ensuring the accuracy and traceability of these measurement devices.

Quality Control in Manufacturing:It is used in quality control processes to ensure that the products meet the required straightness specifications.For example,in the production of flat-panel displays,the straightness of the edges of the glass substrates is crucial for the proper assembly and performance of the display.The granite straight edge can be used to inspect and reject any substrates with unacceptable straightness errors.

OEM with Design

Customization Options:When it comes to OEM with design,customers can request specific dimensions,shapes,and additional features according to their unique application requirements.For example,custom lengths and widths can be designed to fit specific machine tools or measurement setups.Some customers may also ask for special coatings or surface treatments on the granite straight edge to enhance its performance in certain environments,such as anti-static coatings for use in electronic manufacturing.

Incorporation of Design Elements:OEM suppliers can work with customers to incorporate specific design elements into the granite straight edge.This could include the addition of mounting holes or grooves for easy installation and integration into existing equipment or measurement systems.The design can also consider the ergonomics of use,such as adding handles or grips to make it easier to handle and position the straight edge during measurements.

Branding and Labeling:OEM orders often involve branding and labeling the granite straight edges according to the customer's requirements.This can include printing the customer's logo,product model numbers,and relevant technical specifications on the surface of the straight edge.Proper branding and labeling not only help in product identification but also enhance the customer's brand image and product traceability.
