Steel 3d Welding Platform

Selecting a suitable Steel 3d Welding Platform requires comprehensive consideration of many factors.The following are some key points:

Accuracy requirements

If you are engaged in high-precision welding work,such as automotive parts,aerospace and other fields,you need to choose a high-precision Steel 3d Welding Platform,whose flatness,hole spacing tolerance and other indicators should meet high standards,such as flatness tolerance within±0.05mm/m,hole spacing tolerance within±0.05mm.

For general welding processing,such as ordinary mechanical manufacturing and steel structure processing,the accuracy requirements are relatively low.Flatness tolerance is±0.1mm/m-±0.2mm/m,and hole spacing tolerance is±0.1mm-±0.2mm.

Load capacity

The load capacity of the platform is selected according to the weight and size of the actual welding workpiece.If welding large and heavy workpieces,such as the frame of construction machinery and the segmented structure of ships,it is necessary to choose a platform with strong load capacity,which should generally be able to bear several tons or even dozens of tons.

For the welding of small workpieces,such as the shell of electronic equipment,small metal components,etc.,the requirements of load capacity are relatively low,and the platform that can bear the weight of hundreds of kilograms to several tons can be selected.

Material selection

Cast iron material:with good wear resistance,shock absorption and dimensional stability,it is suitable for occasions requiring high accuracy,such as welding in precision instrument manufacturing,mold processing and other industries.

Material of steel parts:high strength,good toughness,and can withstand large impact loads.It is often used to weld large and high-strength workpieces,such as bridge construction,large equipment manufacturing and other fields.

Size specification

The size of the platform shall be determined according to the size of the welding workpiece and the space of the production site.If the size of the workpiece is large,it is necessary to select a larger size platform to ensure that the workpiece can be completely placed on the platform for welding.At the same time,it is necessary to consider that there is enough operation space around the platform.

For batch welding of small workpieces,the platform with smaller size can be selected to improve space utilization and production efficiency.In addition,it is also necessary to consider whether the height of the platform is suitable for the working habits and ergonomic requirements of operators.Generally,the height of 750mm-850mm is more appropriate.

functional requirement

Consider whether the platform needs to be used with automatic welding equipment.If necessary,the platform shall have corresponding interface and installation conditions,so as to accurately connect and cooperate with robots,special welding machines and other equipment.

For some special welding processes,such as rotation,tilt and other operations on the platform,Steel 3d Welding Platform with corresponding functions shall be selected to meet the process requirements.

Brand and after sales

The Steel 3d Welding Platform of well-known brands is usually more guaranteed in product quality and accuracy,and has a perfect after-sales service system,which can provide timely technical support,maintenance and parts supply.

You can refer to the evaluation and use experience of other users to understand the reputation of the brand and the actual performance of the product,so as to make a more wise choice.

budget

Determine a reasonable budget range.Generally speaking,the price of Steel 3d Welding Platform with high precision,strong load capacity and good material is relatively high.On the premise of meeting the use requirements,select products with high cost performance according to their own economic strength.

Don't choose a platform whose quality and performance can't meet the demand just because of the price factor,otherwise it may bring more costs and troubles in the subsequent use process.
