Welding table accessories

Here are some common welding table accessories：

Clamping tools

C-type clamp:shaped like a"C"and available in various sizes and specifications,it generates clamping force by rotating the screw to fix the workpiece on the welding worktable,preventing it from moving during welding.It is suitable for clamping workpieces of various shapes and sizes and is commonly used in simple scenarios such as plate splicing and pipe welding.

T-shaped clamp:Used in conjunction with the T-shaped groove on the welding workbench,the bolt is threaded through the T-shaped groove and the nut of the T-shaped clamp is tightened to achieve rapid clamping and positioning of the workpiece.It is suitable for workpieces that need to be fixed on the T-shaped groove,such as splicing of large plates,welding of frame structures,etc.

Tool welding workbench T-clamp

Magnetic clamp:Using strong magnetic force to attach to the welding workbench,it can quickly fix workpieces with magnetism.It is easy to operate and can improve work efficiency.It is commonly used for welding thin sheets,positioning small parts,etc.,and is not suitable for non-magnetic materials.

Tool welding worktable magnetic clamp

Positioning tools

Positioning pin:It is usually used in conjunction with the positioning holes on the workbench to align the corresponding holes on the workpiece with the positioning pin,which can achieve rapid positioning of the workpiece and ensure the accuracy of the welding position.It is commonly used for welding parts with precise position requirements,such as automotive parts welding,mechanical parts assembly welding,etc.

Tool welding workbench positioning pin

Angle locator:Adjustable angle,used to determine the welding angle of the workpiece,such as 90 degree right angle,45 degree oblique angle,etc.,to ensure the accuracy of the welding angle.It is widely used in welding frame structures,pipeline welding and other scenarios that require angle control.

Tool welding workbench angle locator

Edge locator:installed at the edge of the workbench,used to determine the position of the edge of the workpiece,so that the workpiece maintains neat edge alignment during welding,suitable for splicing welding of plates,welding of boxes,etc.

Tool welding workbench edge locator

Supporting and elevating tools

Support legs:used to support the welding workbench,keeping it at a stable height for operators to perform welding operations.Some support legs also have the function of adjustable height to adapt to different work needs.

Tool welding workbench support leg

Cushion block:usually made of metal materials with different thicknesses and sizes,used to elevate workpieces,maintain a certain distance between workpieces and workbenches,facilitate welding operations and weld formation,commonly used for welding large workpieces,workpieces that require double-sided welding,etc.

Tool welding workbench cushion block

V-shaped block:Shaped in a V-shape,it is used to support and position circular or cylindrical workpieces,keeping them stable during welding and preventing rolling.It is commonly used in pipeline welding,shaft welding,etc.

Tool welding workbench V-block

Other auxiliary tools

Protective barrier:installed around the welding workbench,used to block splashes,sparks,etc.generated during welding,protecting the safety of operators and the surrounding environment,while also reducing eye damage caused by welding light to operators.

Tool welding workbench protective shield

Tool rack:used to place welding tools such as welding guns,welding rods,pliers,etc.,making the tools neatly arranged,easy to access,and improving work efficiency.Different forms and sizes of tool racks can be selected according to needs.

Tool Welding Workbench Tool Stand

Dust collection device:During the welding process,a large amount of smoke and dust will be generated.The dust collection device can effectively collect these smoke and dust,purify the working environment,and protect the health of operators.Common dust collection devices include portable and fixed types.
